Yamaha MG10XUF 10-Channel Mixer w/Faders

Yamaha MG10XUF 10-Channel Mixer w/Faders

$429.00
$519.99 $429.00
Sale Sold out
Taxes included. Shipping calculated at checkout.

Description

Yamaha MG10XUF 10‑Channel Mixer w/Faders

A professional-grade analog mixer that delivers compact versatility with premium features—perfect for studio recording, live sound, installations, DJ setups, and home production.

Design & Build

  • Housed in a powder-coated steel chassis, the MG10XUF is built to endure the rigors of gigging and daily use.

  • Features large linear faders for smooth, precise levels adjustment—ideal for dimly lit environments.

Input & Output Configuration

  • 10 input channels: Includes 4 mono (mic/line) and 3 stereo inputs, plus a stereo bus, auxiliary/FX send, mono monitor out, and headphones.

  • Equipped with balanced XLR stereo outputs, ensuring clean, professional signal routing.

  • Offers +48 V phantom power on all mic channels, enabling seamless use of condenser microphones.

Sound Quality & Control

  • Powered by Yamaha’s acclaimed Class‑A "D‑PRE" mic preamps featuring inverted Darlington circuitry—delivering rich bass, clear mids, and smooth highs with low distortion.

  • Each mono channel includes a 1‑knob compressor for quick dynamics control, alongside a 3‑band EQ, PAD switch, and high‑pass filter.

  • Onboard SPX digital effects offer 24 high-quality programs, including reverb and delay, with parameter adjustment and optional foot-switch control.

Digital Connectivity & Software

  • Functions as a 2-in/2-out USB 2.0 audio interface with up to 24‑bit/192 kHz resolution via USB Class 2.0—ideal for seamless PC, Mac, or iPad use (via Camera Connection Kit).

  • Includes Cubase AI DAW software for desktops and support for Cubasis LE or MG Rec & Play apps on iPad/iPhone.

Specifications

Spec Detail
Dimensions (W×H×D) 275 × 110 × 390 mm (~10.8" × 4.3" × 15.4")
Weight Approx. 3.3 kg (7.3 lbs)
Power Consumption Around 22.9 W


The Yamaha MG10XUF stands out as a compact yet powerful mixing solution. It combines rugged construction with high-end audio performance—Class-A preamps, versatile per-channel controls, pro-grade effects, and digital connectivity. Whether you're recording in the studio, running live sound, streaming, or hooking into a DAW or iPad, it delivers polished results with minimal fuss.
